No |
Working pressure |
Nominal diameter |
Bypass diameter |
|
1 |
140Mpa (20000psi) |
103(4-1/16) |
103(4-1/16) |
|
2 |
105Mpa (15000psi) |
103(4-1/16) |
103(4-1/16) |
|
3 |
70Mpa (10000psi) |
78(3-1/16) |
78(3-1/16) |
|
4 |
35Mpa (5000psi) |
80(3-1/8),52(2-1/6) |
80(3-1/8),52(2-1/6) |
|
5 |
21Mpa (3000psi) |
80(3-1/8),52(2-1/6) |
80(3-1/8),52(2-1/6) |
|
6 |
14Mpa (2000psi) |
80(3-1/8),52(2-1/6) |
80(3-1/8),52(2-1/6) |
Job stress: 2000 psi - 20000 psi
Nominal size: 2.1/16 "to 4.1/16" (46 mm~103 mm)
Working medium: oil, gas and mud
Working temperature: -46 ℃ ~121 ℃(LU)
16 cstandard: API
